SY910 Electric Wheel Loader

Product Introduction

This newly designed 1 ton electric loader adopts green new energy technology.

Equipped with a 0.45m³ bucket,

It has compact structure and highly flexible operation.

Delivering strong power output, the machine achieves energy conservation and emission reduction, which is environmentally friendly for construction, farm and yard work.

Key Features

1. Zero emission mini electric wheel loader
2. compact structure and highly flexible operation.
3. achieves energy conservation and emission reduction.
4. Can equip this loader with different attachments for multi-purpose jobs.

Technical Specifications

Item-perfomance	Specification
Rated Load Capacity	1000 kg
Bucket Capacity	0.45 cbm
Dumping height	2300 mm
Lifting height	3380 mm
Dumping reach	650 mm
Max. lifting weight	1000 kg
Max. excavating force	1100 kg
Max. grade ability	18 °
Max. turning angle	29±1 °
Item-Dimension & weight	Specification
Dimension	4450x1260/1300x2450 mm
wheelbase	1580 mm
Tire spacing	1000 mm
Min groud clearance	215 mm
Net weight	2340 kg
Item-Battery	Specification
No. of battery groups	12
Rated Voltage	72 V
Item-Transmission System-Hydraulic	Specification
Motor No.	YQP5-72AF-48P
Voltage	72 V
Power	5000 w
Displacement	15 ml/r
Rotating speed	2000 r/min
Item-Transmission System-walking	Specification
Motor No.	YQP4-72A1-48P
Voltage	72 V
Power	4000*2 w
Rotating speed	2988 r/min
Item-Transmission System-Tires	Specification
Type	265/75-15.3 29*12.50-15
Working pressure	0.3 Mpa
Qty	4
Item-Steering System	Specification
Type of Steering Hydraulic System	Full Hydraulic Steering System
System pressure	16 Mpa
Type of steering pump	Gear pump
Steering cylinder bore	Φ63-35 mm
Lifting cylinder Qty	2
Item-Brakeing System	Specification
Service brake	Drum brake
Brake drum	240 mm
Dumping Cylinder-Bore	Φ92-45 mm
Lifting Cylinder-Bore	Φ82-40 mm
Lifting Cylinder Qty	2
Item-Oil Capacity	Specification
Hydraulic Oil Tank	54 L
Brake Fluid	0.8 L

Application Scenarios

Construction site material handling
Farm & agriculture work
Quarry and stone yard
Warehouse loading & unloading
Road maintenance and municipal project

Optional Attachments

We can equip this loader with different attachments for multi-purpose jobs:

Standard general bucket / rock bucket
Pallet fork for pallet cargo handling
Log grapple for timber grabbing
Snow bucket / snow blade for snow removal
Quick hitch (quick coupler), fast switch attachments

Packing & Shipment

Shipping container: 20GP /40HQ container
Loading port: Qingdao port, China
Full pre-shipment inspection before loading
Full set export documents for customs clearance

Warranty & After-sales Service

12 months warranty from the date of shipment
Online technical guidance and troubleshooting
Long-term supply of spare parts at competitive price
Pre-shipment full inspection and test run

Product FAQ

Q: What is the rated load of this wheel loader?
A:1000 kg

Q: What attachments can be installed on this loader?
A:This loader supports pallet fork, log grapple, snow bucket, quick hitch and standard bucket.

Q: How long is your warranty period?
A:We provide 12 months warranty for the machine.

Q: Can you supply spare parts after purchase?
A:Yes, we supply original spare parts all the time after sales.
